Astm D93 Standard Pensky Martens Closed Cup Flash Point Tester Automatic

Brand Name : SAMYON

Model Number : SY-261A

Certification : ASTM D93

Place of Origin : CN

MOQ : 1

Price : can be negotiated

Payment Terms : T/T, D/P, D/A, Western Union, MoneyGram

Supply Ability : 999/week

Delivery Time : 3-5days

Packaging Details : wooden box

Power supply : AC( 220±10% )V, 50Hz

Heating rate : (5～6)℃/min

Igniting source : gas

Stirring rate : (90～120)RPM

Relative humidity : ≤80%

Ambient temperature : ≤ 40℃

Contact Now

ASTM D93 Standard SY-261A Automatic Pensky-Martens Closed-Cup Flash Point Tester


Summary
This instrument is designed and manufactured as per standards GB/T 261-2008 Determination of Flash Point - Pensky-Martens closed cup method and ASTM D93 Standard Test Methods for Flash Point by Pensky-Martens Closed Cup Tester. It is used to make determination of the closed cup flash point of the petroleum products.

I. Main technical features
1. Simulation tracking displays function curves of heating up and test time.
2. Equipped with the English prompt function of mis-operation.
3. Equipped with prompt function of test date,test time and other parameters.
4. Automatically calibrate the effect of atmospheric pressure to test and calculate the corrected value.
5. Differential coefficient detection.Automatically correct the system deviation.
6. Automatically open the lid,detect the flash point and print test data.
7. The test arm rises up and lowers down automatically.
8. Igniting with electric igniting gun,forced air cooling.

II. Main technical specifications

Power supply AC( 220±10% )V, 50Hz
Flash point determination ange: Ambient to 300℃.
Repeatability: ≤ 2℃
Reproducibility: ≤ 4℃
Accuracy: 0.1℃
Heating rate

Procedure A: (5～6)℃/min
Procedure B:(1～1.6)℃/min
Automatic control and manually adjustable
Stirring rate Procedure A: (90～120)RPM, Procedure B: (250±10)RPM
Automatic control and manually adjustable.
Igniting mode

(1) Igniting source: gas(or other civilian fuels,the same below)
(2) Electric ignition. Gas flame diameter:3.2mm～4.8mm
Ambient temperature ≤ 40℃
Relative humidity

≤ 80％
Maximum power consumption 500W
